Product Description:
Unique Architectural Design: Our lighting fixtures feature a distinctive aluminum housing that sets them apart in terms of aesthetics and durability.
Easy Installation: The lighting fixtures are designed to be effortlessly installed in pendant, mounted, or recessed configurations, making it convenient for any setting.
Seamless Connection: Enjoy the convenience of seamless daisy chain connections between fixtures, creating a continuous and consistent lighting experience.
Versatile Lighting Options: Choose from a variety of lighting beam angles to suit your space and preference. Additionally, both up and down lighting options are available for further customization.
Customizable Length and Shapes: Tailor the lighting solution to your specific needs with the flexibility to customize the length and combine different shapes, ensuring a perfect fit for any space.
Features:
The lighting fixture offers two options for light efficacy: 125Lm/W and 160 Lm/W. Users can select between a beam angle of 30°, 60°, 90°, or 120° based on their preferences. Additionally, the fixture is dimmable with options including 0-10V (dual channel), Dali 2, and non-dim function.
Users can adjust the wattage to four different levels and tune the correlated color temperature (CCT) to four different settings. Moreover, the fixture provides the option for CRI values greater than 80, greater than 90, or greater than 95. Additionally, motion sensors and emergency battery packs are available as optional features.
Technical Parameters:
| Attribute | Value |
| Application | LED Trunking Lighting System |
| Color Temperature | 3000K / 3500K / 4000K / 5000K |
| Lifespan | 50,000hrs |
| Material | Aluminum + Acrylic/Iron + PS Lens |
| Product Name | LED Trunking Lighting System |
| CRI | >80, >90, >95 |
| Beam Angle | 30°, 60°, 90°, 120° |
| Luminous Efficacy | 125LM/W(Max) |
| Input Voltage | 120-277VAC / 120-347VAC / 220-240VAC |
| Luminous Flux | 3125LM(Max) |
Accessories:
Z10 Receptacle
Features
· Standard Z10 regulated interface.
· Compact Size Allows More Fexibility In Luminaire Design.
· Easily Support Integration With Any Z10 Microwave & PIR Motion Sensor Controls.
· Specially Designed For Highbay Fixtures.
Emergency Pack
Specification
Ambient Temp:Li-ion:32~122°F(0~50°C)
Ni-MH: 41~149°F(5~65°C)
Weight:0.908 lbs(0.41kg)
Surge Protection:Line-Neutral 3KV
Applications:
Super market, office, commercial places, hospital, gym, warehouse, workshop, shopping mall
